Tektelic

Solar LoRaWAN gateway / outdoor · IP67 · off-grid ready
95 W panel · 220 Wh LiFePO4 battery · −30 to +45 °C
EU868 TDD · 8 Rx / 1 Tx · 27 dBm Tx · class A/B/C
4G LTE backhaul · multi-GNSS · 10 kA lightning protection

Solar panel assembly / 50 W · for KONA Photon Gen 2 gateway
Monocrystalline · 20% efficiency · 550 × 540 × 120 mm · 10 kg
Includes mounting knuckle, arm, bracket, U-bolt hardware and ground cable
Compatible with KONA Photon radio module · pole or wall mount

DC power cable / outdoor · 3 m · 2-conductor · 16 AWG
For direct DC power input on KONA Macro and KONA Mega gateways
Pre-terminated CPC connector · weatherproof · 48 VDC nominal

LoRaWAN gateway / outdoor · ATEX Zone 1 · Class I Div 1
EU868 TDD · 16 Rx / 2 Tx · 27 dBm Tx · −142 dBm sensitivity
Dual antenna · adaptive cavity filter · 75 dB isolation
Built-in 4G LTE · PoE 802.3at or 48 VDC · IP66 · 4X

LoRaWAN cold chain sensor / IP67 · −40 to +70 °C · rugged
Ambient temperature + humidity · onboard data logging
LoRaWAN EU868 · screw-mount bracket included
10 years on C-cell LTC · LeapX onboarding · ATLAS

Watermark soil moisture probe / Irrometer 200SS-5 · for KIWI agriculture sensor
Resistive soil tension measurement · reports in centibars / kPa
Connects to KIWI input 5 or 6 · pile/soil mount · outdoor agricultural use
Up to 2 watermark probes per KIWI sensor

Wearable LoRaWAN GPS tracker / IP67 · personnel safety
Fall detection · elevation detection · panic button · geofencing
GNSS (GPS · GLONASS · Galileo · BeiDou) + BLE indoor positioning
15 months on 3× AA · audio & visual alarms · LeapX

LoRaWAN air quality sensor with E-Ink display / indoor · IP30
CO₂ (NDIR) · temperature · humidity · light · barometric pressure
Bundled E-Ink display via BLE · real-time readings at a glance
10 years on 2× AA LTC · wall/ceiling/table mount · BREEZE app

DC power cable / outdoor · 10 m · 2-conductor · 16 AWG
For direct DC power input on KONA Macro and KONA Mega gateways
Pre-terminated CPC connector · weatherproof · 48 VDC nominal

PoE injector / outdoor · 60 W · IEEE 802.3bt · with mounting bracket
100–240 V AC universal input · NA & EU plug compatible
For KONA Macro / Mega / Enterprise gateways · weatherproof installation

Rugged LoRaWAN asset tracker / IP67 · −40 to +70 °C
LoRa Edge™ · GNSS + BLE + Wi-Fi sniffing positioning
Accelerometer · ambient temp/humidity · beacon mode
5+ years on C-cell · optional 12 V external power

Solar panel assembly / 95 W · for KONA Photon Gen 2 gateway
Monocrystalline · 20% efficiency · 970 × 540 × 120 mm · 15 kg
Includes mounting knuckle, arm, bracket, U-bolt hardware and ground cable
Compatible with KONA Photon radio module · pole or wall mount

LoRaWAN air quality sensor / indoor · IP30 · 80 × 80 × 30 mm
CO₂ (NDIR) · temperature · humidity · light · barometric pressure
LoRaWAN EU868 + BLE · pairable with E-Ink display
10 years on 2× AA LTC · wall/ceiling/table mount · BREEZE app

LoRaWAN air quality + occupancy sensor with E-Ink display / indoor · IP30
CO₂ (NDIR) · PIR occupancy · temperature · humidity · light · pressure
Bundled E-Ink display via BLE · real-time readings at a glance
9 years on 2× AA LTC · wall/ceiling/table mount · BREEZE app

ATEX Zone 1/21 LoRaWAN asset tracker / IP67 · outdoor
For explosive atmospheres · oil, gas, mining, processing
LoRaWAN + BLE · dual-mode tracker/beacon · accelerometer
10+ years tracker mode · C-cell · 15 dBm · LeapX

Smart thermostatic radiator valve / Vicki by McLimate · LoRaWAN EU868
Replaces standard radiator thermostat · battery-powered · tool-free installation
Remote temperature control · zone-based heating · OTA configuration
For smart building HVAC management · compatible with major LoRaWAN network servers

BLE navigation beacon / outdoor · IP66 · AA battery powered
Bluetooth Low Energy with unique device ID
For outdoor asset tracking and navigation with Tektelic SPARROW · PELICAN · CHICKADEE
Rugged housing for harsh environments

AC power cord / 2.4 m (8 ft) · 3-wire 18 AWG SJOOW · NEMA 5-15P
North America plug · indoor use · for PoE injectors and AC-powered Tektelic accessories

Passive PoE injector / indoor · 55 W output · AU power plug
1× shielded RJ-45 in · 1× shielded RJ-45 data + power out
10/100/1000 Mbps · overcurrent · overvoltage · short-circuit protection
For KONA Macro · Mega · Enterprise gateways

Passive PoE injector / indoor · 55 W output · NA power plug
1× shielded RJ-45 in · 1× shielded RJ-45 data + power out
10/100/1000 Mbps · overcurrent · overvoltage · short-circuit protection
For KONA Macro · Mega · Enterprise gateways

Wall plug clip / AU and NZ · for Tektelic power adapter T0006008
Snap-on attachment · converts T0006008 base unit to AU/NZ outlet plug
