Accessories | VYNZE

1011.04.JS

MiniFINGER
Outdoor multiband finger antenna / cellular
698–960 · 1710–2170 · 2500–2700 MHz
< 2 dBi gain · 50 Ω · −40 to +85 °C
SMA male · 3.0 m LMR195 · Ø 16 × 220 mm · wall/pole mount

60.00 €

1011.05.JS

FINGER+ SMA
Outdoor finger antenna / cellular
AMPS 850 · GSM 900 · DCS 1800 · PCS 1900 · UMTS 2100 MHz
< 2.2 dBi gain · 50 Ω · −40 to +85 °C
SMA male · 3.0 m RG58 · Ø 15 × 380 mm · wall/pole mount

72.50 €

1011.06.JS

BODY SMA
Outdoor body mount antenna / cellular
GSM 900 · DCS 1800 · PCS 1900 · UMTS 2100 · AMPS 850 MHz
0 dBi gain · 50 Ω · −40 to +85 °C
SMA male · 30 cm RG174 cable · M10 + adhesive mount

40.00 €

1011.07.XS

BODY ECO
Outdoor body mount antenna / cellular
698–960 · 1710–2700 MHz
< 3 dBi gain · 50 Ω · −40 to +85 °C
SMA male · 2.5 m RG174 · Ø 46 × 15 mm · M12 + adhesive mount

32.50 €

1011.40.00

STUB4
Stub antenna / 2G · 3G · 4G
Direct SMA female connector mount

17.50 €

1011.40.XS

STUB ECO
Stub antenna / direct-mount cellular
698–960 · 1710–2690 MHz
3 dBi gain · 50 Ω · −40 to +85 °C
SMA male · Ø 10 × 50 mm · direct connector mount

13.75 €

1015.20.02

LiPo rechargeable battery / 300 mAh
3.7 V nominal · 4.2 V charge · Molex 5264-2P
Charge 0–45 °C · Discharge −20–60 °C
20 × 38 × 6 mm · 50 mm cable · for Avior

35.00 €

2505.00.01

RJ45 to DB9 configuration cable
Communication · configuration · control · tracing
Compatible with Avior · Naos.III · Mobi.Control · Mobi.Key

27.50 €

2505.00.03

RJ45 to USB configuration cable
Communication · configuration · control · tracing
Compatible with Avior · Naos.III · Mobi.Control · Mobi.Key

37.50 €

2507.00.01

RJ45 to RS485 converter / 15 cm cable included
Compatible with Avior · AviorEco

62.50 €

2900.P1.AT

BLE temperature sensor / IP67 · IK09
Bluetooth 5.0 · 70 m range · −40 to +85 °C
1200 mAh replaceable battery · up to 44 months
70 × 48 × 24 mm · 53 g · for Avior (max 4)

65.00 €

2900.S4.1A

BLE door/window sensor / tamper switch
Bluetooth 5.0 · 100 m range · −20 to +60 °C
CR2032 220 mAh replaceable · up to 13 months
55 × 26 × 13 mm · 27 g · for Avior (max 10)

60.00 €

2900.SD.00

microSD card / 128 MB · blank
−20 to +70 °C

6.50 €
