MIG2TEEU868

Name: MIG2TEEU868
Price: 373.0 EUR
Availability: InStock

The TEKTELIC KONA Micro Gen2T (MIG2TEEU868) is a compact indoor LoRaWAN gateway for enterprise and lightweight industrial IoT deployments demanding "always-on" connectivity. This Ethernet-only EU868 variant offers 8 Rx / 1 Tx time-duplex architecture, 27 dBm Tx power, and Listen Before Talk for spectrum-efficient European operation. A factory-installed lithium-ion backup battery keeps the gateway running for up to 4 hours during mains power loss. It supports 12 VDC or PoE (IEEE 802.3bt Class 3) and is compatible with major public and private LoRaWAN network servers. Plug-and-play deployment via Tektelic's LeapX app and remote management via Kona Pilot OAM.

Note: Other regional channel plans (US915, AU915, AS923, IN865) and variants with built-in 4G LTE cellular backhaul are available on request — please contact us for a quote.

Terms and Conditions

Key features

LoRaWAN EU868Time-duplex 8 Rx / 1 Tx · 27 dBm Tx power · external antenna

Battery backupUp to 4 hours operation during mains power loss · included

Ethernet backhaulRJ-45 10/100BaseT · 12V DC or PoE 802.3bt

Enterprise-grade reliabilityMTBF 830 000 h · CE/RED · IP30 indoor enclosure

Network server flexibleTektelic Core NS · ChirpStack · TTN/TTI · Loriot · Semtech UDP

Remote managementSSH · SNMPv3 · HTTPS · in-service updates · Kona Pilot OAM

Technical Specs

LoRa radio

Channel plan	EU868 (other plans available on request)
Architecture	Time-duplex · 8 Rx / 1 Tx
Tx power	14 dBm to 27 dBm
Rx sensitivity	−141 dBm (SF12, 293 bits/s)
Rx noise figure	3.5 dB
Rx linearity	−10 dBm
Rx dynamic range	70 dB analog · 100+ dB digital
Listen Before Talk	Enabled per regional standards
Antenna connector	Reverse SMA female (external antenna included)

Backhaul & interfaces

Ethernet backhaul	RJ-45 · 10/100BaseT
Cellular backhaul	None (Ethernet-only model · LTE variant available on request)
LoRa antenna	Reverse SMA female
Power input	12 V DC barrel jack or PoE
Status indicator	Multi-function LED

Power supply

DC input	12 VDC ±10% · 1 A max · barrel jack 2.1/5.5 mm (center positive)
PoE input	IEEE 802.3bt Class 3 (802.3af compatible) · Mode A/B/4-pair
PoE voltage	48 VDC nominal (37–57 VDC operating range)
Power consumption	2.3 W (Ethernet) · 2.6 W (cellular variant)
AC adapter included	Region-specific plug (EU/UK or NA/JP)

Backup battery

Type	Lithium-ion (replaceable)
Voltage	7.4 V
Backup time	Up to 4 hours
Charging	Automatic when DC/PoE power is connected
Included	Yes (factory-installed)

Software & management

Network servers	Tektelic Core NS · ChirpStack · TTN / TTI · Loriot · Semtech UDP
Management	Kona Pilot OAM · KonaFT field tool · LeapX onboarding
Remote access	SSH (port 22) · SNMPv3 (161) · HTTPS (443) · mDNS (5353) · ICMP
Networking	DHCPv4 client · TFTP server · HTTP server · firewall · ACLs
Updates	Active & passive image management · in-service updates
Provisioning	Factory image provisioning for mass deployment

Mechanical & environmental

Dimensions	120 × 118 × 41.5 mm
Weight	336 g (with battery) · 245 g (without)
Operating temperature	0 °C to +40 °C (without battery) · 0 °C to +38 °C (with battery)
Relative humidity	5–95% RH (condensing)
Operating altitude	−60 m to 4 000 m
Ingress protection	IP30 (indoor use only)
MTBF	830 000 hours
Mounting	Flat surface or wall (M3 screws · 60 mm spacing)

Other channel plans: This product page covers the EU868 variant (MIG2TEEU868). Versions for US915, AU915, AS923 (variants 1–4), JP923 and IN865 channel plans are available on request — please contact us for a quote.

What's in the box: KONA Micro Gen2 gateway · 12 VDC AC adapter (region-specific plug) · LoRa RF antenna · 1 m Ethernet cable · test sheet · getting started guide. Battery is factory-installed.

Documentation

KONA Micro Gen2 Product Page (Tektelic)

KONA Micro Gen2 User Guide (PDF)
